Programming Manual of FC2005/FC901
6|63 A6V10333724_b_en_--
1.1 Communication Port Connector
The communication port is connected to the USB port of the computer that has the FXS901-U2 programming
tool. This is used to upload and/or download panel configuration if this method of programming is used.
The computer must be disconnected from the panel if not in use.
1.2 LEDS, Buzzer and Dedicated Push Buttons
The LEDs operate as follows:
Item LED Color Status Description
1
Alarm Red
Steady ON
There are alarm events, and all alarm events have
been acknowledged.
OFF There is no alarm event in system.
Flashing
There are alarm events in system, but some of
them have not been acknowledged.
2
Power
(US)
Power On
(Canada)
Green
Steady ON
The system's power works normally. Both the
main power and battery are in normal status.
OFF
The system is not powered on. This LED can be
OFF only when the system is shut down.
Flashing
The main power is in trouble and system is
powered via battery.
3
Silenced
(US)
Signal
Silence
(Canada)
Yellow
Steady ON All outputs which can be silenced are silenced.
OFF There are no silenced outputs in system.
Flashing Both silenced and unsilenced outputs exist.
4 Trouble Yellow
Steady ON
There are trouble events, and all of them have
been acknowledged.
OFF There is no trouble event in system.
Flashing
There are trouble events in system, but some of
them have not been acknowledged.
5 Supervisory Yellow
Steady ON
There are supervisory events, and all of them
have been acknowledged.
OFF There is no supervisory event in system.
Flashing
There are supervisory events in system, but some
of them have not been acknowledged.
6 Ground Fault Yellow
Steady ON There are Ground Fault events in system.
OFF There is no Ground Fault event in system.
Flashing
There are ground fault events in system, but some
of them have not been acknowledged.
7
Audible On
(US)
Alarm
Signal
Activation
(Canada)
Red
Steady ON
The LED 7 can only be steady on when any of the
following conditions are met:
1. There are activated NACs and some of them
are not silenced.
2. There are silenceable devices activated and
some of them are not silenced.
OFF
The LED 7 will be OFF when above conditions are
not met.
