Programming Manual of FC2005/FC901
A6V10333724_b_en_-- 7|63
The buzzer operates as follows:
Normally OFF – indicates that the system is in normal condition or all events in the system have been
acknowledged.
ON (200 pulse per minute) – indicates that at least ONE unacknowledged alarm is present in the system.
ON (85 pulse per minute) – indicates that at least ONE unacknowledged non-alarm (trouble, supervisory)
event is present in the system.
The buttons operates as follows:
Item Button Action Description
8
Programmable (US)
Press
Press button 8 to execute user defined and configured functions.
Alarm Signal Activation
(Canada)
Press button 8 to report the alarm zone events to the panel.
9
Silence/Unsilence (US)
Press
The button toggles between silence and unsilence. Press button
9 to silence the audible and/or visual notification appliances
(where permitted by the codes and control panel programming).
The notification appliances will be de-activated, and the LED 3
will be off. Press button 9 again to unsilence the previously
silenced notification appliances.
Signal Silence/Unsilence
(Canada)
10 Acknowledge/Buzzer Silence Press Acknowledges all unacknowledged events in system.
17 Reset Press
Clears all obsolete events and resets all devices, except those
disabled ones and hold-through-reset devices in system.
11 C Press Cancel button for PMI operation.
12 OK Press OK button for PMI operation.
13 * Press * button for PMI operation.
14 # Press # button for PMI operation.
15 0-9 Press
Numeric buttons for PMI operation. They are used to enter the
password to access the maintenance and technician modes of
the panel. It allows the user to program the panel using these
keypads without using the FXS901-U2 programming tool.
16 Menu Press Menu button for PMI operation.
18 Four-way button Press A four-way button for menu navigation.
