Programming Manual of FC2005/FC901
A6V10333724_b_en_-- 21|63
6. HOW TO DO DEVICE TEST
Function: Before doing device test on site, set device as test mode so that alarm will be released faster.
Steps for device test:
1. Select a device by navigating hardware tree (Fig. 9-1).
2. Press “Menu” to display the main menu (Fig. 9-2).
3. Press “→” to select “Oper” submenu (Fig. 9-3). Press “↓” to
select “Device Test” and press “OK” to set the device as test
mode and it will be shown under realtime event list.
You can view device property (Fig. 9-4). The device test
parameter is set as “True”.
Steps for Quit Device Test:
Same as the steps to device test. The only difference is to select
“Quit D.Test” instead of “Device Test” in step 3 (Fig. 9-5). The
device test event will disappear under realtime event list.
Fig.9-1
Fig.9-2
Fig.9-3
Fig.9-4
Fig.9-5
