Programming Manual of FC2005/FC901
34|63 A6V10333724_b_en_--
16. HOW TO CREATE/DELETE DIALER GROUP
Function: Dialer Group is used to reduce the number of messages reported to supervising station. For
example: if two zones both detect alarm condition but they are close to each other, sending one piece of
alarm message will be enough to inform the supervising station, meanwhile, this behavior can reduce costs.
There is one dialer group by default. Newly created zones are added automatically to the default dialer group.
Physical devices are not included in dialer group. They are reported as system level messages.
Steps of creating:
1. Press “Menu” to display the main menu (Fig.19-1).
2. Press “↓” to select “Dialer group” item and press “OK” (Fig.
19-2), dialer group screen is displayed (Fig.19-3).
3. Press “Menu” to display the main menu, press “→” to select
“Conf” submenu, to select “Create” and press “OK” (Fig.19-4) ,
create screen is displayed (Fig.19-5). There are two parameters
(type and name) which need to be configured.
4. To select “Type” and press “OK”, one default type (dialer group)
is listed (Fig.19-6). Press “OK”, the screen returns to the
previous screen and the selected type is shown (Fig.19-7).
5. To select “Name” and press “OK”, an input text screen is
displayed. To enter a right name (i.e., “Siemens1) and press
“OK”, the screen returns to the previous screen and the new
name is shown (Fig.19-8).
6. To select “Confirm” and press “OK”, the new dialer group is
created and shown (Fig.19-9).
Fig.19-1
Fig.19-2
Fig.19-3
Fig.19-4
Fig.19-5
To Next Page
