Siemens FC2005 Programming Manual

Programming Manual of FC2005/FC901
A6V10333724_b_en_-- 19|63
5. HOW TO DO QUICK TEST
Function: To test installation quickly and easily. The installed device can be activated and NACs can be
activated for a short period of time. The quick test menu allows user to configure quick test parameters. User
can stop the quick test manually. Quick test mode will automatically quit when the quick test time is out.
The following parameters can be configured before doing quick test:
Parameters Description Value Default
Quick Test Time
Set the time interval of system quick test. The FACP
will quit automatically Quick Test mode after the
configured time expires. When quick test ends, FACP
will reset all events automatically.
{Min.: 5;
max.: 30;}
30
Disable Output
Set if the output is disabled during quick test. If it is
configured as True, FACP will not activate any output
on events in Quick Test mode. If it is configured as
False, output can be activated manually or
automatically in Quick test mode.
{True; False} True
Annunciator Off
Set if the annunciator is off during quick test. If it is
configured as True, no events in Quick Test mode will
be forwarded to annunciators. If it is configured as
False, events in Quick Test mode will be forwarded to
annunciators as configured.
{True; False} False
History Off
Set if the history is off during quick test. If it is
configured as True, no events in Quick Test mode will
be recorded in history. If it is configured as False,
events in Quick Test mode will be recorded in history.
{True; False} False
NAC Off
Set if the NAC is off during quick test. If it is configured
as True, NAC shall not respond to any events in Quick
Test mode. If it is configured as False, NAC shall
respond as configured in Quick Test mode.
{True; False} False
