# Text Description Action
1044 ? Board overheating on %4 All PICs: A module temperature greater
than the defined maximum operating
temperature (default 65°C) has been de‐
tected.Overheating must be corrected as
soon as possible to avoid permanent
damage to the analyzer electronics, in‐
cluding reduced module life expectancy
or other board failures.
Note: This alarm can occur together with
alarm 1005 (Temp Diag Error) in which
case the board may not actually be over‐
heating.
This alarm concerns the temperature in
the electronics enclosure. This alarm is
not related to the Overtemp Shutdown
related to heater temperature controls.
If the overheating condition is real, de‐
termine and correct the cause of high
operating temperature.
Possible causes include ambient tem‐
perature higher than specification or an
inoperative fan in the electronics enclo‐
sure (restricted air flow inside the EC).
1045 ? Output Locked on %4 All PICs: The state of the DO or the value
of the AO are locked and cannot be
changed. The AO or DO command was
ignored. Some DO and AO are locked
during a board self-test.
When performing a board self-test, sus‐
pend all other operations affecting the
board.
1047 ? PIC firmware diagnostic 47
on %4
System error Contact Customer Support.
1048 ? PIC firmware diagnostic 48
on %4
System error Contact Customer Support.
1049 ? PIC firmware diagnostic 49
on %4
System error Contact Customer Support.
1050 ? PIC firmware diagnostic 50
on %4
System error Contact Customer Support.
1051 ? PIC firmware diagnostic 51
on %4
System error Contact Customer Support.
1052 ? PIC firmware diagnostic 52
on %4
System error Contact Customer Support.
1053 ? PIC firmware diagnostic 53
on %4
System error Contact Customer Support.
1054 ? PIC firmware diagnostic 54
on %4
System error Contact Customer Support.
1055 ? PIC firmware diagnostic 55
on %4
System error Contact Customer Support.
1056 ? PIC firmware diagnostic 56
on %4
System error Contact Customer Support.
1081 + Data Not Ready on %4 All PICs: The data requested is not avail‐
able.
Contact Customer Support.
1082 + Reset Detect on %4 %5 All PICs: A reset was detected. Normal
indication that the PIC was reset.
No action necessary.
1083 + Power Up on %4 %5 All PICs: A power-up cycle was detected.
Normal indication that the PIC was pow‐
ered up.
No action necessary.
General Maintenance and Troubleshooting
4.6 Alarm Codes, Descriptions, and Suggested Actions
Maxum edition II Analyzer General Maintenance
Manual, August 2018, A5E42019842001 49
