MicroSAM
Operating Instructions, 06/2012, C79000-G5376-C560-07
105
Technical data
9
Climatic conditions
Permissible ambient temperature -20 to 50 °C (depending on oven temperature)
Permissible storage/transport temperature -30 °C to +70 °C
Permissible relative humidity Max. 90%
Protection against dust and moisture:
In accordance with EN 60529 / IEC 60529
IP 65
In accordance with NEMA 250
NEMA 4X
Power supply
Supply voltage Up to AS08: 24 V DC (+10% to -15%)
From AS08 onwards: 24 V DC (18.5 V to 30.2 V)
External fuse T 2.5 A
Power consumption, typical 18 W
Power consumption, maximum 60 W
Dimensions and weights
Dimensions 360 x 300 x 220 (width x depth x height in mm)
Weight Approx. 20 kg
Mounting
Installation on Post, pipe or wall
Distance from wall or next chromatograph 300 mm
Distance from ceiling or floor 200 mm
