Description
3.3 MicroSAM design
MicroSAM
Operating Instructions, 06/2012, C79000-G5376-C560-07
21
3.3 MicroSAM design
The following illustration provides an overview of the most important MicroSAM modules.
① MicroSAM housing ⑧ Gas connections with blanking plugs
② Main cover ⑨ Pressure controller
③ Analysis module ⑩ RSP module
④ Lock nut ⑪ EPC module
⑤ Insulating cover ⑫ Spacer
⑥ Earthing connection ⑬ Side cover
⑦ Metal bracket ⑭ Communications and power supply cable
Figure 3-1 MicroSAM design
