Description
3.4 Rating plate design
MicroSAM
22 Operating Instructions, 06/2012, C79000-G5376-C560-07
3.4 Rating plate design
The rating plate is located on the housing and contains the Order No. and other important
product information.
① Vendor ⑤ CSA marking with CSA data
② CE marking ⑥ IEC marking
③ Ex marking with Ex data ⑦ Serial number and release version (RV)
④ Consult operating instructions
Figure 3-2 Rating plate
