3.5 Functional description of the electronics
MicroSAM
24 Operating Instructions, 06/2012, C79000-G5376-C560-07
RSP (real-time signal processing) and CAC (communication and analytical control)
563
&$&
Figure 3-3 RSP and CAC
EPC (electronic pressure control)
Figure 3-4 EPC
