Service and maintenance
6.1 Maintenance of analysis module
MicroSAM
82 Operating Instructions, 06/2012, C79000-G5376-C560-07
6. Loosen the M6 lock nut using a ring spanner A/F 10 ①.
7. Completely unscrew the M14 nut.
8. Unscrew the screw on the pulling tool as shown below.
