Page #52 background imageLoading...
Page #52 background image
5 Firewall configuration using the example of a SCALANCE SC632-2C
Service Bridge Setup and Configuration
Entry ID: 109747975, V1.4, 05/2019
52
Siemens AG 2019 All rights reserved
Note
If the interfaces are interchanged, SCALANCE SC loses its protection function.
5.2 SCALANCE SC632-2C configuration
The SCALANCE SC632-2C is configured using Web Based Management (WBM).
Note
The configuration of the firewall with the Security Configuration Tool (SCT) is not
supported by the SCLANCE SC family.
Requirement
To configure SCALANCE SC632-2C, it must be first reset to factory settings.
You can reset the SCALANCE SC632-2C to factory settings by pressing and
holding the reset button for about 5 seconds during device start-up until the Fault
"F" LED is constantly lit.
Furthermore, at least firmware version V2.0 is required.
Note
The firmware can be downloaded from the following entry:
https://support.industry.siemens.com/cs/de/en/view/109764481
5.2.1 Setting up access to the Web Based Management of the SCALANCE
SC632-2C
To configure the SCALANCE SC632-2C, the first step is to establish the
connection to Web Based Management.
1. Assign the previously defined IP address "192.168.10.12" and subnet
mask "255.255.255.0" as described in chapter 3.2
2. Access the WBM and carry out the steps described in chapter 3.3
(changing the password, checking and updating the firmware version if
necessary).
