Data transfer to the PLC
7.1 Interface to S7-300 and control/diagnosis via PROFIBUS
3WL/3VL circuit breakers with communication capability - PROFIBUS
148 System Manual, 03/2011, A5E01051353-02
Step 3 Configuring the DP settings
Select the module rack by clicking on it.
Then double-click on the line with the DP interface in the module rack.
"Properties - DP..."
The diagnostics address property may be needed later for software creation. You can find
this information under the "Addresses" tab.
