Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
228 System Manual, 03/2011, A5E01051353-02
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
34 Neutral point voltage phase L3 202 Meter. fct. — unsigned
int
16 0
36 Mean value of phase-to-phase voltage 203 Meter. fct. — unsigned
int
16 0
38 Mean value of neutral-point star voltage 204 Meter. fct. — unsigned
int
16 0
40 Total apparent power 217 Meter. fct. — unsigned
int
16 0
42 Total active power 221 Meter. fct. — signed int 16 0
44 Active power in phase L1 222 Meter. fct. — signed int 16 0
46 Active power in phase L2 223 Meter. fct. — signed int 16 0
48 Active power in phase L3 224 Meter. fct. — signed int 16 0
50 Total reactive power 225 Meter. fct. — signed int 16 0
52 Long-time mean value of 3-phase active
power
229 Meter. fct. — signed int 16 0
54 Long-time mean value of active power in
phase L1
230 Meter. fct. — signed int 16 0
56 Long-time mean value of active power in
phase L2
231 Meter. fct. — signed int 16 0
58 Long-time mean value of active power in
phase L3
232 Meter. fct. — signed int 16 0
60 Long-time mean value of 3-phase apparent
power
233 Meter. fct. — unsigned
int
16 0
62 Apparent power in phase L1 218 Meter. fct. — unsigned
int
16 0
64 Apparent power in phase L2 219 Meter. fct. — unsigned
int
16 0
66 Apparent power in phase L3 220 Meter. fct. — unsigned
int
16 0
68 Long-time mean value of apparent power in
phase L1
234 Meter. fct. — unsigned
int
16 0
70 Long-time mean value of apparent power in
phase L2
235 Meter. fct. — unsigned
int
16 0
72 Long-time mean value of apparent power in
phase L3
236 Meter. fct. — unsigned
int
16 0
74 Long-time mean value of 3-phase reactive
power
237 Meter. fct. — signed int 16 0
76 Reactive power in phase L1 226 Meter. fct. — signed int 16 0
78 Reactive power in phase L2 227 Meter. fct. — signed int 16 0
80 Reactive power in phase L3 228 Meter. fct. — signed int 16 0
82 Active energy in normal direction [MWh] 238 Meter. fct. — unsigned
long
32 0
86 Active energy in reverse direction [MWh] 239 Meter. fct. — unsigned
long
32 0
90 Reactive energy in normal direction [MVArh] 240 Meter. fct. — unsigned
long
32 0
