Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
229
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
94 Reactive energy in reverse direction [MVArh] 241 Meter. fct. — unsigned
long
32 0
98 Mean value of the power factor 168 Meter. fct. — signed int 16 –3
100 Power factor in phase L1 169 Meter. fct. — signed int 16 –3
102 Power factor in phase L2 170 Meter. fct. — signed int 16 –3
104 Power factor in phase L3 171 Meter. fct. — signed int 16 –3
106 Frequency 262 Meter. fct. — unsigned
int
16 –2
108 THD of current 254 Meter. fct. — unsigned
char
8 0
109 THD of voltage 257 Meter. fct. — unsigned
char
8 0
110 Form factor 261 Meter. fct. — unsigned
char
8 –1
111 Peak factor 260 Meter. fct. — unsigned
char
8 –1
112 Frequency 3VL 396 — — unsigned
char
16 -2
114 Temperature in the control cabinet (measured
in the COM15)
71 COM15 — unsigned
char
8 0
115 Temperature in circuit breaker (measured in
the BSS)
330 BSS — unsigned
char
8 0
116 Active energy in normal direction [kWh] 433 Meter. fct. — unsigned
long
32 —
120 Active energy in reverse direction [kWh] 434 Meter. fct. — unsigned
long
32 —
124 Reactive energy in normal direction [kVArh] 435 Meter. fct. — unsigned
long
32 —
128 Reactive energy in reverse direction [kVArh] 436 Meter. fct. — unsigned
long
32 —
132 Reserved — — — unsigned
char
32 —
136 Property byte for byte 116 (active energy in
normal direction)
— Meter. fct. — PB 8 —
137 Property byte for byte 120 (active energy in
reverse direction)
— Meter. fct. — PB 8 —
138 Property byte for byte 124 (reactive energy in
normal direction)
— Meter. fct. — PB 8 —
139 Property byte for byte 128 (reactive energy in
reverse direction)
— Meter. fct. — PB 8 —
140 Property byte for byte 0 (phase unbalance
current (in %))
— Meter. fct. ETU PB 8 —
141 Property byte for byte 2 (long-time mean
value of 3-phase current)
— Meter. fct. ETU PB 8 —
142 Property byte for byte 4 (long-time mean
value of current L1)
— Meter. fct. — PB 8 —
