Siemens SENTRON VL Series

Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
230 System Manual, 03/2011, A5E01051353-02
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
143 Property byte for byte 6 (long-time mean
value of current L2)
— Meter. fct. — PB 8 —
144 Property byte for byte 8 (long-time mean
value of current L3)
— Meter. fct. — PB 8 —
145 Property byte for byte 10 (current in phase L1) — ETU ETU PB 8 —
146 Property byte for byte 12 (current in phase L2) — ETU ETU PB 8 —
147 Property byte for byte 14 (current in phase L3) — ETU ETU PB 8 —
148 Property byte for byte 16 (mean current value
over the three phases)
— ETU ETU PB 8 —
149 Property byte for byte 18 (current in neutral
conductor)
— ETU ETU PB 8 —
150 Property byte for byte 20 (current that flows to
ground)
— ETU ETU PB 8 —
151 Property byte for byte 22 (phase unbalance
voltage
(in %))
— Meter. fct. — PB 8 —
152 Property byte for byte 24 (phase-to-phase
voltage between phase L1 and L2)
— Meter. fct. — PB 8 —
153 Property byte for byte 26 (phase-to-phase
voltage between phase L2 and L3)
— Meter. fct. — PB 8 —
154 Property byte for byte 28 (phase-to-phase
voltage between phase L3 and L1)
— Meter. fct. — PB 8 —
155 Property byte for byte 30 (neutral point
voltage phase L1)
— Meter. fct. — PB 8 —
156 Property byte for byte 32 (neutral point
voltage phase L2)
— Meter. fct. — PB 8 —
157 Property byte for byte 34 (neutral point
voltage phase L3)
— Meter. fct. — PB 8 —
158 Property byte for byte 36 (mean value of
phase-to-phase voltage)
— Meter. fct. — PB 8 —
159 Property byte for byte 38 (mean value of
neutral point voltage)
— Meter. fct. — PB 8 —
160 Property byte for byte 40 (total apparent
power)
— Meter. fct. — PB 8 —
161 Property byte for byte 42 (total active power) — Meter. fct. — PB 8 —
162 Property byte for byte 44 (active power in
phase L1)
— Meter. fct. — PB 8 —
163 Property byte for byte 46 (active power in
phase L2)
— Meter. fct. — PB 8 —
164 Property byte for byte 48 (active power in
phase L3)
— Meter. fct. — PB 8 —
165 Property byte for byte 50 (total reactive
power)
— Meter. fct. — PB 8 —
166 Property byte for byte 52 (long-time mean
value of 3-phase active power)
— Meter. fct. — PB 8 —
