Data library
8.6 Data sets
3WL/3VL circuit breakers with communication capability - PROFIBUS
System Manual, 03/2011, A5E01051353-02
231
Byte Description Data
point
Source
WL
Source
VL
Format Length
(bits)
Scaling
167 Property byte for byte 54 (long-time mean
value of active power in phase L1)
— Meter. fct. — PB 8 —
168 Property byte for byte 56 (long-time mean
value of active power in phase L2)
— Meter. fct. — PB 8 —
169 Property byte for byte 58 (long-time mean
value of active power in phase L3)
— Meter. fct. — PB 8 —
170 Property byte for byte 60 (long-time mean
value of 3-phase apparent power)
— Meter. fct. — PB 8 —
171 Property byte for byte 62 (apparent power in
phase L1)
— Meter. fct. — PB 8 —
172 Property byte for byte 64 (apparent power in
phase L2)
— Meter. fct. — PB 8 —
173 Property byte for byte 66 (apparent power in
phase L3)
— Meter. fct. — PB 8 —
174 Property byte for byte 68 (long-time mean
value of apparent power in phase L1)
— Meter. fct. — PB 8 —
175 Property byte for byte 70 (long-time mean
value of apparent power in phase L2)
— Meter. fct. — PB 8 —
176 Property byte for byte 72 (long-time mean
value of apparent power in phase L3)
— Meter. fct. — PB 8 —
177 Property byte for byte 74 (long-time mean
value of 3-phase reactive power)
— Meter. fct. — PB 8 —
178 Property byte for byte 76 (reactive power in
phase L1)
— Meter. fct. — PB 8 —
179 Property byte for byte 78 (reactive power in
phase L2)
— Meter. fct. — PB 8 —
180 Property byte for byte 80 (reactive power in
phase L3)
— Meter. fct. — PB 8 —
181 Property byte for byte 82 (active energy in
normal direction)
— Meter. fct. — PB 8 —
182 Property byte for byte 86 (active energy in
reverse direction)
— Meter. fct. — PB 8 —
183 Property byte for byte 90 (reactive energy in
normal direction)
— Meter. fct. — PB 8 —
184 Property byte for byte 94 (reactive energy in
reverse direction)
— Meter. fct. — PB 8 —
185 Property byte for byte 98 (mean value of
power factor)
— Meter. fct. — PB 8 —
186 Property byte for byte 100 (power factor in
phase L1)
— Meter. fct. — PB 8 —
187 Property byte for byte 102 (power factor in
phase L2)
— Meter. fct. — PB 8 —
188 Property byte for byte 104 (power factor in
phase L3)
— Meter. fct. — PB 8 —
189 Property byte for byte 106 (frequency) — Meter. fct. — PB 8 —
