Siemens SIMATIC 505 User & Programmers Manual

Sample Operator Interface Screens
A-14
ANALOG MAINTENANCE
F1
MACHINE
OVERVIEW
F2
MACHINE
UTILIZE
F3
PROCESS
PROFILES
F4 F5
GRAPH
ALARM
TEMP
LOOPS
F6
MAIN
MENU
ZONE
1 TEMP INPUT WX–33 200 200 F 7.50 0–10V
ZONE 2 TEMP INPUT WX–34 225 225 F 7.55 0–10V
ZONE 3 TEMP INPUT WX–35 200 250 F 7.60 0–10V
ZONE 4 TEMP INPUT WX–36 225 275 F 7.65 0–10V
ZONE 5 TEMP INPUT WX–37 200 300 F 3.00 0–5V
ZONE 6 TEMP INPUT WX–38 225 275 F 2.95 0–5V
ZONE 7 TEMP INPUT WX–39 200 250 F 2.90 0–5V
ZONE 8 TEMP INPUT WX–40 225 225 F 2.85 0–5V
WA TER TEMP INPUT WX–41 192 192 F 8.75 0–10V
WA
TER FLOW INPUT WX–42 20 20 gpm 5.25 0–10V
CLAMP POSITION OUTPUT V–450 10.2 10.2 in 6.70 0–10V
CLAMP POSITION INPUT V–451 10.4 10.4 in 6.80 0–10V
CLAMP PRESSURE OUTPUT V–452 1500 1500 psi 3.50 0–10V
CLAMP PRESSURE INPUT V–453 1510 1510 psi 3.55 0–10V
RAM POSITION OUTPUT V–454 5.8 5.8 in 4.75 0–10V
RAM POSITION INPUT V–455 5.9 5.9 in 4.80 0–10V
RAM PRESSURE OUTPUT V–456 1300 1300 psi 3.10 0–10V
RAM PRESSURE INPUT V–457 1303 1303 psi 3.13 0–10V
DESCRIPTION TYPE LOCATION UNSCALED SCALED VOLTAGE RANGE
Figur e A-13 Analog Maintenance
