Operating the device
5.5 Trusted Platform Module (TPM)
SIMATIC IPC PX-39A
60 Operating Instructions, 08/2022, A5E51699601-AA
5.5 Trusted Platform Module (TPM)
Depending on the configuration you ordered, your device may have a Trusted Platform
Module according to the TPM 2.0 standard. The Trusted Platform Module is a chip that
enhances your device with security functions. It provides an improved protection from
manipulation of the PC.
NOTICE
Import restrictions for the Trusted Platform Module
Use of the Trusted Platform Module is subject to legal restrictions in some countries and is
not permitted there.
• Be sure to observe the respective import restrictions of the country in which the device
will be used.
Activate the Trusted Platform Module
You can find information on activating the Trusted Platform Module in the detailed
firmware/BIOS description, see "Important instructions and manuals for operating the device
(Page 10)".
5.6 Buffer memory NVRAM (optional)
Depending on the configuration ordered, the motherboard is equipped with an NVRAM that
applications can use to back up data in the event of a power failure.
Failure of the supply voltage for a duration longer than 5 ms is indicated by the DC FAIL
signal.
Depending on the system utilization, up to 512 KB can be saved in the NVRAM. A memory
window with a maximum size of 512 KB can be displayed by means of a PCI address register.
The base address is initialized by the BIOS.
A corresponding function is implemented there for using the SIMATIC Software Controller.
