Installing and connecting the device
3.2 Installing the device
SIMATIC IPC PX-39A
Operating Instructions, 08/2022, A5E51699601-AA
35
3.2 Installing the device
3.2.1 Installation guidelines
Procedure during installation and mounting
WARNING
Dangerous voltage and fire hazard
Improper actions during installation and assembly may lead to personal injury and/or
substantial damage to equipment.
You should observe the installation and assembly notes under:
• Notes on mounting (Page 23)
• Notes on ambient and environmental conditions (Page 23)
NOTICE
Insufficient load carrying capacity
If the wall it is mounted on does not have a sufficient load-bearing capacity, the device may
fall and be damaged.
• Ensure that the mounting surface on the wall can bear four times the total weight of the
device, including fixing elements.
NOTICE
Incorrect fixing elements
The device may not be securely fitted if you use fixing elements other than those specified
below for mounting. The device can fall and may be damaged.
•
Use only the specified fixing elements.
Note
•
See the notes under Preparing the mounting cutout (Page 33).
•
For installation in control cabinets, note the SIMATIC setup guidelines as well as the
relevant DIN/VDE requirements or the country-specific regulations.
•
Provide adequate volume in the co
ntrol cabinet for air circulation and heat transport. Keep
at least 50 mm distance between the device and control cabinet.
•
The ventilation slots of the device may not be covered or obstructed.
•
Ensure there is enough clearance in the control cabinet to allow the backplane cover to be
removed.
•
Equip the control cabinet with struts for stabilizing the mounting cut-out. Install struts
where necessary.
See also
Mounting positions (Page 32)
