Siemens SIMATIC IPC PX-39A User Manual

Technical specifications
8.8 Technical specifications of graphics/display
SIMATIC IPC PX-39A
90 Operating Instructions, 08/2022, A5E51699601-AA
8.8 Technical specifications of graphics/display
See the note in "Applicability of technical specifications (Page 82)".
Graphics controller
Graphics controller
Intel® UHD Graphics 16 EUs:
• Intel® Celeron® 6600HLE
• Intel® Xeon® W-11155MLE
Intel® UHD Graphics 32 EUs:
• Intel® Xeon® W-11865MLE
•
Intel® Xeon® W-11555MLE
Resolutions/frequencies/colors
DisplayPort: Max. 4096 × 2304 / 60 Hz / 36 bits
Display
15"
19"
22"
24"
Display type
LCD TFT with ex-
tended viewing
angle
LCD TFT with ex-
tended viewing
angle
LCD TFT with ex-
tended viewing
angle
LCD TFT with ex-
tended viewing an-
gle
Active display area
344 x 194 mm
410 x 230 mm
475 mm x 267 m
m
527 mm x 296.5 m
m
Resolution
1920 x 1080
pixels
1920 x 1080 pix-
els
1920 x 1080 pix-
els
1920 x 1080 pixels
Displayable colors
Up to 16.7 million
Brightness control
Yes, value range 0 to 99
1
0 = backlighting off
Backlight
Half-brightness
Lifetime (MTBF
1, 2
)
LED
50000 h
LED
50000 h
LED
30000 h
LED
30000 h
Pixel error class in
accordance with
ISO 9241-307
II
Power consump-
tion
14 W
25 W
25 W
32 W
1
Via SetBrightness dialog: 9 to 99 (≙ 10 to 100%),
via SetBrightness command line call: 0 to 99
2
MTBF: Operating hours after which the maximum brightness is reduced by half compared to the
original value. MTBF is increased by using the integrated dimming function, for example, time-con-
trolled via screen saver or centrally via PROFIenergy.
