Siemens SIMATIC IPC277D

Technical specifications
9.4 Technical specifications
SIMATIC IPC277D
122 Operating Instructions, 12/2016, A5E03409486-AE
Graphics
Display, resolution
• 7" screen diagonal with backlighting,
resolution 800 × 480 pixels, WVGA, WGA (Wide VGA)
• 9" screen diagonal with backlighting,
resolution 800 × 480 pixels, WVGA, WGA (Wide VGA)
• 12" screen diagonal with backlighting,
resolution 1280 × 800 pixels, WXGA (Wide XGA)
• 15" screen diagonal with backlighting,
resolution 1280 × 800 pixels, WXGA (Wide XGA)
• 19" screen diagonal with backlighting,
resolution 1366 x 768 pixels
Touch controller Resistive Semtech controller ELO CTR-2216SU-AT-CHP-00
Touch screen analog resistive
Touch force with test pen; 2 mm diameter: 5 N
Backlighting (MTBF)
Half brightness life time, typical
LED
min. 50000 h at 50 °C, 50% brightness
Pixel error class in accordance
with ISO 9241-307
II
Interfaces
COM 1
RS232, max. 115 kbps, sub-D connector, 9-pin
USB
• 3 × USB 2.0, a maximum of 2 can be operated in high-
current mode at the same time
• IPC277D 15"/19": 1 x front USB 2.0 high current
LAN interface X1 P1, RJ45
1
Intel Platform Controller Hub EG20T Gigabit Ethernet
10, 100, 1000 Mbps
LAN interface X2 P1, RJ45
1
Intel 82574L Gigabit Ethernet controller
10, 100, 1000 Mbps, teaming is supported
2
Keyboard, mouse
Connection via USB port
1
For unique labeling, the LAN interfaces are numbered on the enclosure. The numbering by the
operating system can differ.
2
Teaming can be set and initiated in the configuration interface. In teaming operation, jumbo
frames, e.g. for the camera application, are not supported.
