Siemens SIMATIC IPC277D

SIMATIC IPC277D
Operating Instructions, 12/2016, A5E03409486-AE
77
Device expansion and parameter assignment
7
7.1
Open the device.
Observe the information in section "ESD guideline (Page 112)".
Requirement
● The device is disconnected from the power supply.
● All cables have been disconnected from the device.
● The device has been removed from the control cabinet.
● A T10 screwdriver
Procedure - opening IPC277D 7" and 9"
Remove the marked screws
Remove the rear panel.
