Siemens SIMATIC IPC277D

Overview
1.2 Configuration of the devices
SIMATIC IPC277D
Operating Instructions, 12/2016, A5E03409486-AE
13
1.2
Configuration of the devices
1.2.1
SIMATIC IPC277D 7"
Front and side view
①
Display/touch screen
②
Mounting clamp recess
③
Mounting seal
Rear view
①
Rating plate
②
Interface designation
