Siemens SIMATIC IPC277D

Technical specifications
9.4 Technical specifications
SIMATIC IPC277D
Operating Instructions, 12/2016, A5E03409486-AE
127
9.4.5.3
DC power supply
Input voltage
24 VDC (19.2 to 28.8 VDC)
Power consumption
1
Max. 72 W
Power failure buffering Hold-up time > 15 ms
(DC_FAIL becomes active after > 5 ms)
Maximum continuous output power
1
60 W
1
The performance specifications apply to the power supply component, but not to the device.
Note
Inrush current
The device needs an inrush current of at least 4.5
A for 25 ms.
The peak value of the inrush current depends on the input voltage and the impedance of the
24 V source; peak currents in excess of 4.5 A are possible. This will not have a negative
impact on device functionality.
