Siemens SIMATIC IPC277D

Device maintenance and repairs
8.3 Installing and removing hardware
SIMATIC IPC277D
88 Operating Instructions, 12/2016, A5E03409486-AE
8.3.4
Replacing drives of IPC277D 7" and 9"
Carry out the procedure if you want to replace an SSD with an SSD.
Please observe the information in section "Repair information (Page 82)".
Requirement
● The device is opened.
See section "Open the device. (Page 77)".
● An SSD
● A T10 screwdriver
Procedure - removal
For information on the removal of the backup battery and battery holder, refer to section
"Replacing the backup battery (Page 85)".
Note
Do not remove the
battery connector. If you remove the battery connector, you will have to
reinstall the BIOS.
Remove the
battery holder.
Remove the marked screws.
