Device maintenance and repairs
8.3 Installing and removing hardware
SIMATIC IPC277D
Operating Instructions, 12/2016, A5E03409486-AE
89
Put down the backup battery.
The marked connector must
remain connected.
Remove the connector from the
SDD
Remove the drive and put it
as
ide.
Remove the marked screws.
Put down the drive carrier panel
and the drive.
For installation, follow these steps in reverse and close the device.
