Siemens SIMATIC IPC277D

Technical specifications
9.4 Technical specifications
SIMATIC IPC277D
Operating Instructions, 12/2016, A5E03409486-AE
125
9.4.4.2
Power consumption
Normal power consumption (7" device)
Power consumption
(at 24 V rated voltage)
Basic device ATOM 1.0 GHz,
1 GB RAM with display
18 W
Basic device ATOM 1.3 GHz,
2 GB RAM with display
18 W
SSD
2 W
Expansion USB, max.
6 W
Normal power consumption (9" device)
Power consumption
(at a rated voltage of 24 V)
Basic device ATOM 1.0 GHz,
1 GB RAM with display
21 W
Basic device ATOM 1.3 GHz,
2 GB RAM with display
21 W
SSD
2 W
USB extension, max.
6 W
9.4.4.3
DC power supply
Input voltage
24 VDC (19.2 to 28.8 VDC)
Power consumption
Max. 32 W
Power failure buffering Hold-up time > 15 ms
(DC_FAIL becomes active after > 5 ms)
Maximum continuous output power
1
25 W
1
The power specifications apply to the power supply component not to the device.
Note
Inrush current
The inrush current of the device at an input
voltage of 24 V amounts to at least 2 A for a
period of 25
ms.
The peak value of the inrush current depends on the input voltage and the impedance of the
24 V source; peak currents in excess of 2.0 A are possible. This will not have a negative
impact on de
vice functionality.
