Technical specifications
9.6 BIOS description
SIMATIC IPC277D
136 Operating Instructions, 12/2016, A5E03409486-AE
The screen is divided into four sections. In the top section ②, you can select the submenus
[Main], [Advanced], [Security], [Power], [Boot], [Version], [Exit]. You can select various
settings or submenus in the left middle section
③. Short help texts are displayed on the right
④ for currently selected menu entries; the bottom section contains information for operator
input.
The following figures represent examples of specific device configurations. The screen
content may deviate slightly depending on the equipment actually supplied.
You can move between the menu forms using the cursor keys [←] left and [→] right.
Advanced Advanced system configuration
Security functions, e.g. setting a password
Power Specify startup characteristics of the device, e.g. in response to specific events, in
case of power failure, or in power saving mode.
Set boot options, e.g. the boot priority.
Device-specific information (e.g. product version)
