Installing and connecting the device
3.1 Preparing for installation
SIMATIC IPC277D
34 Operating Instructions, 12/2016, A5E03409486-AE
● Vertical installation in upright format, display turned through ±90 ° compared with the
standard position
For vertical installation in upright format, the following ambient temperatures are
permitted:
Maximum ambient temperature at the device
45 °C 40° C 40° C The device must be installed in a fire protec-
tion enclosure (see "General safety instruc-
tions (Page 23)").
