Siemens SIMATIC IPC277D

Installing and connecting the device
3.1 Preparing for installation
SIMATIC IPC277D
36 Operating Instructions, 12/2016, A5E03409486-AE
The following table shows the dimensions of the required mounting cutout:
Mounting cutout
Device
7 inch
9 inch
12 inch
15-inch
19-inch
Width w
*
197
+1
mm
251
+1
mm
310
+1
mm
396
+1
mm
464
+1
mm
Height h
*
141
+1
mm
166
+1
mm
221
+1
mm
291
+1
mm
318
+1
mm
*
Width and height should be reversed accordingly when mounting in vertical format.
