Installing and connecting the device
3.2 Installing the device
SIMATIC IPC277D
38 Operating Instructions, 12/2016, A5E03409486-AE
IP65 degree of protection
Danger of electric shock when degree of protection is not guaranteed
The specified degree of protection cannot be guaranteed if the device is not correctly
installed. Moisture or water could leak in and cause electric shock or destroy the plant.
The degree of protection IP65 is ensured for the front of the device under the following
conditions:
•
The mounting cutout was prepared bas
ed on the correct dimensions; see chapter "Pre-
paring the mounting cutout (Page 35)".
• The device was secured with the supplied mounting clamps or with clamps which can
be optionally ordered.
• The mounting seal is undamaged.
Technical specifications (Page 120)
Dimension drawings (Page 115)
Preparing the mounting cutout (Page 35)
