Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC277D
46 Operating Instructions, 12/2016, A5E03409486-AE
Switch off the 24 VDC power supply.
Connect the wires of the power supply.
Connect the connection terminal at the
marked positi
on.
Technical specifications (Page 120)
