Expanding and assigning parameters to the device
6.6 Installing and removing drives
106 Operating Instructions, 01/2021, A5E43920357-AA
Number of drives
per system
Mounting location in drive
cage type A
Installation option
6
Drive cage type A:
• Mounting location 0
• Mounting location 1
• Mounting location 2
• 2.5" drive or 3.5" drive in removable tray (Page 107)
• 3.5" drive in removable tray (Page 107)
• Mounting location 3 • 2.5" drive or 3.5" drive in removable tray (with 5.25" mounting
frame) (Page 109)
•
5.25" drive or 5.25" component (Page 121)
• 2 x internal in the device • 2 x HDD inside on the side panel of the device (Page 123)
Possible drive configurations in drive cage type A
You can implement the following drive configurations in the drive cage type A and on the
side panel of the device.
• Non-RAID system
• Onboard RAID1 system
• Onboard RAID5 system
• Onboard RAID1 system with hot-spare drive
• Onboard RAID5 system with hot-spare drive
