Product description
1.5 Internal construction of the device
34 Operating Instructions, 01/2021, A5E43920357-AA
1.5 Internal construction of the device
①
Power supply, single or redundant (here in the example: Single power supply)
②
Heat sink of the processor
③
Rod with card holders for expansion cards
④
Slots for memory modules
⑤
Drive cage (here in the example: Drive cage type A or type B)
⑥
Guide rail for long expansion cards
⑦
Motherboard
⑧
Expansion card slots
⑨
Slot brackets (numbering of the slots for expansion cards on the enclosure)
