Expanding and assigning parameters to the device
6.6 Installing and removing drives
Operating Instructions, 01/2021, A5E43920357-AA
107
6.6.1.2 Change 2.5" and 3.5" drive in removable tray
Requirement
• You know the important safety instructions under "Safety instructions on device and
system extensions (Page 48)".
• An original spare part, that is, a drive approved for this device.
• You can find information on the removable tray as a replacement part under "Hardware
accessories (Page 35)".
• The device is equipped with the drive cage type A.
• You know the information under "Installation conditions for drives in drive cage type A
(Page 105)".
• When replacing an HD: T10 screwdriver
• When replacing an SSD: T8 screwdriver
• The device you wish to replace is inactive.
NOTICE
Risk of damaging the drive and data loss
Drives in removable trays can only be exchanged in conjunction with RAID1 and RAID5
during operation (hot swap).
When you remove the drive while data is being written to it, you may damage the drive
and destroy data.
• Only remove the removable tray from the device when the drive is inactive, see
"Status displays on removable tray for drives (Page 33)".
Procedure
1. If there is no RAID system:
Fully disconnect the device from the line voltage, see "Switching off the device (Page 72)".
2. Open the front panel (Page 75).
3. Open the lock of the removable tray with the appropriate key.
