Installing and connecting the device
3.3 Connecting the device
64 Operating Instructions, 01/2021, A5E43920357-AA
3.3.4.3 Connecting several monitors (multi-monitoring)
Connection of monitors for devices with SMS-H410 motherboard
and optional P400 graphics card
For connecting monitors to the internal graphics card, there are 2 connection sockets on the
rear of the device as standard.
• DP (DisplayPort; labeling on the device: DPP1)
• DVI-D
You will find three additional connection sockets on the rear of the device for connecting
monitors to the optional P400 graphics card.
• 3 x mDP
You can use adapters to connect monitors to other graphics ports at the connection sockets
of the optional P400 graphics card.
You can find information on the connection sockets on the rear of the device under: "Device
ports (Page 24)".
You can find information on the adapters under "Hardware accessories (Page 35)".
Connection socket on monitor Connection socket on the
Connection socket on the optional P400 graphics
DP
2
DVI-D
2
mDPP1 mDPP2 mDPP3
1)
1)
1)
1)
1)
1)
1)
via adapter, see "Hardware accessories"
2)
Labeling on the device
