Expanding and assigning parameters to the device
6.6 Installing and removing drives
Operating Instructions, 01/2021, A5E43920357-AA
105
6.6 Installing and removing drives
6.6.1 Installing drives in drive cage type A
6.6.1.1 Installation conditions for drives in drive cage type A
Number of drives per system and their mounting locations
You can install up to six drives at the following bays in the drive cage type A and on the side
panel of the device.
Note the numbering of the mounting locations in the drive cage type A. (Page 18)
Number of drives
per system
Mounting location in drive
cage type A
Installation option
1
Drive cage type A:
• Mounting location 0
• 2.5" drive or 3.5" drive in removable tray (Page 107)
2
Drive cage type A:
• Mounting location 0
•
Mounting location 1
• 2.5" drive or 3.5" drive in removable tray (Page 107)
3
Drive cage type A:
• Mounting location 0
• Mounting location 1
• Mounting location 2
• 2.5" drive or 3.5" drive in removable tray (Page 107)
4
Drive cage type A:
• Mounting location 0
• Mounting location 1
• Mounting location 2
• 2.5" drive or 3.5" drive in removable tray (Page 107)
Drive cage type A:
• Mounting location 3
• 2.5" drive or 3.5" drive in removable tray (with 5.25" mounting
frame) (Page 109)
• 5.25" drive or 5.25" component (Page 121)
5
Drive cage type A:
• Mounting location 0
• Mounting location 1
• Mounting location 2
• 2.5" drive or 3.5" drive in removable tray (Page 107)
• Mounting location 3 • 2.5" drive or 3.5" drive in removable tray (with 5.25" mounting
frame) (Page 109)
•
5.25" drive or 5.25" component (Page 121)
1 x internal in the device
• 1 x HDD inside on the side panel of the device (Page 121)
