Installing and connecting the device
3.3 Connecting the device
62 Operating Instructions, 01/2021, A5E43920357-AA
4. Switch the device on using the on/off switch (position |).
The status display on the power supply modules light up green.
Note
If only one of the power supply modules works, a warning signal sounds. You turn off the
warning
signal by pressing the alarm reset button on the working power supply module.
You can find information on the position of the alarm reset button under "
Operator
5. To prevent unintentional disconnection of the power plug, secure the power plug on the
device.
6. Remove the two retaining screws ①.
7. Screw on the power plug latches ② with the two fixing screws ①.
