Accessories
C.1 TS modules
CP 1243-8 IRC
196 Operating Instructions, 02/2018, C79000-G8976-C385-03
Note
Use the supplied cable wi
th ferrite to comply with EMC values and make sure that the ferrite
To use the TS Module Modem outside Germany, you can fit a country-specific TAE
connector onto the RJ11 connector of the phone cable. For Germany, a TAE6N connector is
supplied. In some countries, telephone jacks with RJ-11 sockets are available, so that the
telephone cable can be used without TAE connectors.
● Dimensions (WHD): 30 x 100 x 75 mm
● Weight: 98 g
● ITU transmission standards:
V.21, V.22, V.22bis, V.23, V.32, V.32bis, V.34, V.34x, K56flex, V.90, V.92
● Error correction and data compression
● a/b port
● Hayes command set (AT)
● All data formats
● Dialing mode: Multifrequency signaling (DTMF), pulse dialing
The TS Module Modem is designed so that worldwide use is possible. When installing and
operating the TS Module Modem, keep to the country-specific laws and special features.
The TS module has a telecommunications approval in the following countries:
Australia
Iceland
Poland
Belgium
Italy
Portugal
Bulgaria
Canada
Romania
Denmark
Latvia
Sweden
Germany
Lithuania
Switzerland
Estonia
Luxembourg
Slovakia
Finland
Malta
Slovenia
France
New Zealand
Spain
Greece
Netherlands
Czech Republic
Great Britain
Norway
Hungary
Ireland
Austria
USA
Cyprus
For information on approval in other countries, please contact Technical Support.
