Configuration
4.2 Required STEP 7 products
CP 1243-8 IRC
58 Operating Instructions, 02/2018, C79000-G8976-C385-03
Ports of communications partners and routers
Make sure that you enable the required client ports in the corresponding firewall on the
communications partners and in intermediary routers.
These can be:
● MSC / 26382 (TCP) - configurable with a central interface: 1024 .. 65535
● NTP / 123 (UDP)
● DNS / 53 (UDP)
● SINEMA RC and OpenVPN / 1194 (UDP) - can be set
● SINEMA RC autoconfiguration / 443 (TCP) - can be set in SINEMA RC
Required STEP 7 products
Configuration in STEP 7
You will find the required STEP 7 products and versions in the section Requirements for
operation (Page 23).
You require the following for the configuration:
You perform the entire configuration in STEP 7 Basic or STEP 7 Professional.
You will find the description of the procedure as of the section Configuration in STEP 7 Basic
(Page 66).
CP as replacement TIM 3V-IE Advanced
You configure the CP in the following configuration tools one after the other.
You require the following for the configuration:
●
– Configuration of a proxy for the CP (PROXY CP1243-8 IRC) in an S7-300 station
– Configuration of the connected WAN networks and connections in the SINAUT
engineering software
Note
Configuration of connections
Remember to create the connections to be used by the CP in the STEP 7 V5 project.
– Exporting the configuration data
You will find the description of the procedure in the section STEP 7 V5 configuration of
the proxy (Page 215).
