Accessories
C.1 TS modules
CP 1243-8 IRC
200 Operating Instructions, 02/2018, C79000-G8976-C385-03
● Dimensions (WHD): 30 x 100 x 75 mm
● Weight: 100 g
● Type of traffic: Full duplex
● Transmission mode: Asynchronous
● Signals: TXD, RXD, DSR, CTS, RTS, DTR, DCD
● Transmission speed: 2400...115200 bps
● Frame format: 8 data bits (LSB first), no parity bit, 1 stop bit
● Standard: RS-232
● D-sub male connector: 9-pin, male (PC COMx)
Note
The device is designed for industrial use.
The TS Module GSM has an interface for the connection of a GSM/GPRS antenna and a
tray for a SIM card.
The antenna connection and the slot for the SIM card are located behind the lower front
panel.
For the antenna, refer to the section Antennas (Page 208).
CSD data connection (Circuit Switched Data)
For outgoing calls, the TS Module GSM supports GPRS and CSD data connections.
For incoming calls, only CSD data connections are accepted.
