Configuration
4.19 Messages
CP 1243-8 IRC
Operating Instructions, 02/2018, C79000-G8976-C385-03
163
Partner stations
4.18.13.1
Partner configuration for ST7 data points
Enabling the partner for the ST7 data point
Enable all partners to which a telecontrol connection was configured and with which the
selected data point will exchange data. To do this select the relevant "
" check box.
You can configure or change the partners in the overview table or in the "Partner stations"
tab of the module. The data will be adopted at the other point.
Partner configuration for DNP3 and IEC data points
Enabling the partners for data points - DNP3 / IEC
Enable all configured partners with which the selected data point will exchange data. You
specify the communications partners of the CP in the "Partner stations" parameter group.
●
In the overview table of the data points, as default Partner 1 is set as the partner of a data
point.
In the "Partner stations" tab, in this case Partner 1 is enabled, the option grayed out.
●
If you enable a different partner or more partners for this data point in the overview table,
these will be enabled in the "Partner stations" tab and all 4 partners can be selected or
deselected.
Message configuration
SMS
If important events occur, the CP can send SMS messages to a mobile phone.
You configure the SMS message in STEP 7 in the data point and message configuration.
You can find this using the project tree:
Project > directory of the relevant station > Local modules > CP
For the view in STEP 7, refer to the section Data point configuration (Page 128).
