CP 1243-8 IRC
Operating Instructions, 02/2018, C79000-G8976-C385-03
215
STEP 7 V5 configuration of the proxy
D
Note
Using the CP
The information on configuration in STEP
7 V5 applies only in the situation when you
want to
use the CP as a communication module with the functions of a TIM
3V-IE Advanced in
existing SINAUT ST7 systems.
See also
Expansion of SINAUT projects (Page 35)
D.1
Configuration in STEP 7 V5
Configuration of a proxy in STEP 7 V5
1. Open the STEP 7 V5 project that you wish to expand with S7-1200/1500 modules.
2. Create an S7-300 station with CPU and the new necessary networks, if applicable.
The CPU only serves as placeholder to receive the SINAUT subscriber number.
3. Insert the "proxy" in the station.
4. Perform the configuration in STEP 7.
Deviations from the normal configuration are described below.
5. Perform the configuration in the connection configuration of the SINAUT engineering
software.
6. Export the configuration data of the proxy via the SINAUT diagnostics and service tool.
For information on this, refer to section Exporting configuration data (Page 221).
The data exported from STEP 7 V5 is adopted later in the STEP 7 Basic project for the
S7-1200/1500 communication module.
PROXY modules in HW Config
You can find the proxy modules as representatives of S7-1200/1500 communication
modules in the HW Config catalog under:
SIMATIC 300 > SINAUT ST7 > TIM IE

Siemens SIMATIC S7-1200 CP 1243-8 IRC Specifications

General

Product Type	Communication Processor
Series	SIMATIC S7-1200
Model	CP 1243-8 IRC
Data Transfer Rate	10/100 Mbps
Power Supply	24 V DC
Mounting	DIN rail
Dimensions (W x H x D)	45 mm x 100 mm x 75 mm
Digital Inputs Quantity	0
Digital Outputs Quantity	0
Supported Protocols	ISO-on-TCP
Interface	Ethernet
IP Addressing	Static, DHCP
Configuration	STEP 7 Basic/Professional
Operating Temperature	-20°C to +60°C
Weight	Approx. 200 g
