Tool operations
3.11 Reset CPU memory
SIMATIC Automation Tool V2.1 user guide
48 Manual, V2.1.1 07/2016, A5E33042676-AC
3.11
Reset CPU memory
Reset memory on selected CPUs
Use the following steps to reset CPU memory on selected devices.
1.
Click the left
-side check box on devices to include in the operation. You can use
the top check bo
x, right-click shortcut menu, or the Edit menu for "Select All" and
"Unselect All" commands.
2.
Select "Memory Reset" from the Network menu or click the "Memory Reset"
toolbar button.
3.
Click the "Continue" button on the "Memory Reset" dialog box.
4.
Selected CPUs perform a memory reset operation.
5.
The Event log below the device table shows the results of this operation.
The selected devices in the following image perform a memory reset when the Memory
Reset command is executed.
