Data Exchange with the Central Controller
IP244
C79000–B8576–C860–02
4–62
Message 18
This message contains the manipulated variables of controllers 0 to 12. The output is in the form
of a percentage. The following assignments apply:
Range 0 x 100 => heating at x%
Range 101 x 127 => range not permitted (does not occur)
Range 128 x 228 => cooling at x – 128%
Range 229 x 65535 => range not permitted (does not occur)
!
!
!
!
!
!
!
!
!
!
!
!
!
Fig. 2.5/2 Structure of message 18
(manipulated variables)
