3 Function
Controlling the IP 244 temperature controller module.
3.1 Calling the Function Block
: JU FB162
Name : PER:TREG
ADRA :
BGAD :
DBNR :
BEF :
TĆNR :
ANST :
NEUA :
PAFE :
AFEH :
BFEH :
SFEH :
KANR :
FMLD :
in LAD/CSF (Ladder Diagram or Control
System Flowchart):
in STL (Statement list) :
FB162
PER:TREG
ADRA NEUA
BGAD PAFE
DBNR AFEH
BEF BFEH
TĆNR SFEH
ANST KANR
FMLD
3.2 Explanation of the Parameters
Name
Type
of
para.
Type
of
data
Meaning
ADRA D KF Type of addressing
BGAD D KF Module address
DBNR D KY Specification of the first data block
BEF D
KC
Specification of the command to be executed
TĆNR D
KF
Message number
ANST I
BI
Trigger with direct parameter assignment
NEUA Q
BI
Cold restart - request from the module
PAFE Q
BI
Parameter assignment error
AFEH Q
BI
Sampling error (sampling time exceeded)
BFEH Q
BI
Module error (watchdog)
SFEH Q
BI
Group error (all channels)
KANR Q
BY
Number of channel with error
FMLD Q
W
Error bytes of channel with error
