Test Program

6–5

IP244

C79000–B8576–C862–02

3 Signal Assignments for the

Test Program

Digital inputs:

I 4.0 PA Assign parameters

I 4.1 IW Read actual values

I 4.2 LE Read the parameters of one controller

I 4.3 AE Change the parameters of one controller

I 4.4 AS Change the setpoints of one controller

I 4.5 AB Switch over to automatic operation

I 4.6 HB Switch over to manual operation

I 4.7 S1 Switch over to setpoint 1

I 5.0 S2 Switch over to setpoint 2

I 5.1 T1 Controller not disabled if tolerance 2 violated

I 5.2 T2 Controller disabled if tolerance 2 violated

I 5.3 G1 Do not output averaged manipulated variable (*)

I 5.4 G2 Output averaged manipulated variable (*)

I 5.5 Read curve values channel 13 (direct function) (*)

I 5.6 Read actual value channel 14 (direct function) (*)

I 5.7 End of machine cycle (direct function) (*)

I 6.0 2

I 6.1 2

I 6.2 2

Controller number (T-NR)

I 6.3 2

I 6.4 2

I 6.5 Free

I 6.6 Free

I 6.7 Free

I 7.0 Type of parameter assignment (0: indirect parameter assignment, 1: direct

parameter assignment)

I 7.1 Free

I 7.2 Free

I 7.3 Free

I 7.4 Free

I 7.5 ST Start/stop self-tuning function (*)

I 7.6 Free

I 7.7 Clear error number (PAFE)

(*)

These functions can only be selected in the test program with indirect parameter assignment.
