Application of the Function Block
5–51
IP244
C79000–B8576–C861–02
Select software switch:
Free
Assignment of the right data byte DR 6 DBĆA:
Automatic reading after selfĆtuning complete
Read out to alternative data block DBĆA' and DBĆC'
Bit 0: if this bit is set, the parameters calculated after completion of the selfĆtuning function
(controllerĆspecific, e.g. controller 0: message 0 and message 30) are read by the
module and stored in the data block (evaluation of the selfĆtuning status bit).
Bit 1: if this bit is set, the controller messages are stored in the alternative data blocks DBĆA'
and DBĆC' either automatically or with the command "LE".
Bits 2 to 7 are not assigned.
Free
Free
Free
Free
Free
76543210
