Test Program
6–13
IP244
C79000–B8576–C862–02
FB 63 shows the application of function block FB 162 with indirect parameter assignment.
Structural diagram FB 63
Check flags of FW 4 und F 7.5 for rising edge x=0
Formulate job (next page)
Segment 3:
Is a job currently active? (DBĆA: DW1 = 0?)
No
Segment 2:
edge evaluation of flag word FW 4 (<--> IW 4)
edge evaluation of flag F 7.5 (<--> I 7.5)
Segment 1:
parameters
call the assigned data block
Segment 5:
channel number --> F 8.4 to F 8.7
Segment 6:
Block end
Segment 4:
Call FB 162 : JU FB 162
NAME : PER: TREG
ADRA : KF +0
BGAD : KF +0
DBNR : KY 0,0
BEF : KS x
TĆNR : KF +0
ANST : F 2.0
NEUA : F 8.0
PAFE : F 11.0
AFEH : F 8.1
BFEH : F 8.2
SFEH : F 8.3
KANR : FY 24
FMLD : FW 9
Yes
To Next Page
